Description
IC200BEM003 PROFIBUS Master Module
DESCRIPTION
GE Fanuc’s IC200BEM003 is a Versamax PROFIBUS master module. Handles 3584 I/O points with speeds from 9.6k to 12M baud. Supports 125 slave devices with Sync/Freeze modes. Compact design (4.3×2.63×1.95 in) for industrial networks. UL-certified for hazardous areas.
TECHNICAL DATA
| Brand | GE Fanuc |
| Model | IC200BEM003 |
| Series | Versamax |
| Network | PROFIBUS |
| I/O Capacity | 3584 inputs + 3584 outputs |
| Slave Devices | Up to 125 |
| Isolation | 1500V AC (network to backplane) |
INSTALLATION GUIDE
- Use shielded twisted pair cabling
- Terminate both ends of linear bus topology
- Connect via 9-pin D-sub connector
- Configure with Windows-based software
- Power: 450mA @5V DC
PACKAGING LIST
- IC200BEM003 Master Module
- Mounting accessories
SHIPPING METHODS
Fast global delivery via FedEx, UPS, DHL
FAQ
Q: How many devices can connect?
A: Supports up to 125 slave devices.
Q: What cable type required?
A: Use shielded twisted pair with proper termination.
Q: Configuration software needed?
A: Requires Windows-based utility for setup.
