Description
Product Overview
The IS200TTURH1CFD comes from GE Energy.
It is a Terminal Turbine Board (TTUR) for the Mark VIe series.
This board works as a terminal for 48 input/output connections.
It also controls the 52G main breaker relay coil on the VTUR assembly.
The board has a conformal coating to protect against harsh conditions.
It is a modified version of the IS200TTURH1 with extra revisions.
Technical Specifications
Manufacturer: GE Energy
Part Number: IS200TTURH1CFD
Series: Mark VIe
Product Type: Terminal Turbine Board
Functional Acronym: TTUR
PCB Coating: Conformal Coating
Functional Revision 1: C
Functional Revision 2: F
Artwork Revision: D
I/O Connections: 48 total (24 per terminal block)
Mounting: Factory-drilled holes
Special Feature: Shield bar on left-hand side
Suffix Information
IS200 → Base series code for GE Mark VIe family
TTUR → Functional acronym for Terminal Turbine Board
H1 → Base board designator
C → First functional revision
F → Second functional revision
D → Artwork revision
Hardware Features
Two pluggable terminal blocks with screw mounts for easy removal
Six connector ports with clear nomenclature labels
Shield bar running along the left side
Wiring support for TTL speed pickups
Factory-drilled mounting holes for secure installation
Conformal coating protects the board from dust and moisture
Easy Installation & Maintenance
Each terminal block uses two screws for simple attachment.
You can remove the blocks without special tools.
The board works with Versamax systems for extended I/O needs.
Mount the board using the pre-drilled holes.
The conformal coating reduces failure risks in dirty environments.
Compatibility
This board fits the Mark VIe Turbine Control System.
It works with the VTUR Turbine Control Board assembly.
Use it to add 48 I/O points to your turbine setup.
It replaces the older IS200TTURH1 model.
Package Contents
One IS200TTURH1CFD Terminal Turbine Board
Pre-installed conformal coating
No cables or terminal blocks included (blocks shown for reference)
Warranty & Shipping
12-month warranty covers manufacturing defects.
We ship worldwide via FedEx, UPS, or DHL.
Tracking number sent after dispatch.
Typical delivery: 3 to 7 business days.
Frequently Asked Questions (FAQ)
1. What does the conformal coating do on this board?
It protects the circuit from moisture, dust, and chemical exposure.
2. My VTUR board is not reading signals correctly. Could this TTUR board be the problem?
Yes. Check the two terminal blocks first. Loose screws cause signal loss on the 48 I/O points.
3. Can I use IS200TTURH1CFD with older Mark V systems?
No. This board only works with Mark VIe series systems.
4. How do I know if I need the C and F revision levels?
Check your system manual. Newer revisions like C and F fix known issues from earlier versions.
5. What is the difference between IS200TTURH1 and IS200TTURH1CFD?
The CFD version adds C and F functional revisions plus D artwork revision. It is more reliable.
Selection Guide
First, confirm your system is Mark VIe (not older Mark V or Mark VI)
Next, count your needed I/O points – this board gives 48 total
Then, check if you need the 52G breaker relay control function
For harsh environments, the conformal coating is a must-have
Choose this CFD revision over older H1 for better reliability
