Description
MTL5017: Safe and Reliable Switch/Proximity Interface for Hazardous Areas
Control two hazardous-area sensors safely from your control panel. The MTL5017 interface lets you use standard switches or NAMUR proximity detectors located in explosive atmospheres (like Zone 0) to control safe-area relays. It features independent phase reversal on each channel and advanced line fault detection (LFD) for open or short circuits, ensuring operational safety and reliability.
Technical Data
Brand: MTL
Model: 5017
Input Channels: 2
Input Type: NAMUR/DIN 19234 proximity or dry contact
Hazardous Area Rating: Zone 0, IIC, T6 / Div. 1, Group A
Output Signal: 2 Single-Pole Relay Outputs (NO)
Supply Voltage: 20 – 35 V DC
Power Consumption: < 55 mA
Line Fault Detection: Open-circuit (Iin <100µA) & Short-circuit (Rin <100Ω)
Contact Rating: 10VA, 250V AC / 10W, 220V DC
Termination: 14-pin terminal block
Compatibility Notes
Compatible with all NAMUR-type proximity detectors and standard mechanical switches. Designed for use in Class I, Division 1, Group A and Zone 0, IIC hazardous locations.
Certification & Safety
Designed to meet stringent international standards for use in hazardous areas. Um = 250V.
Package Contents & Warranty
Package Includes: 1 x MTL5017 Interface Unit.
Shipping: Fast global shipping via FedEx, UPS, or DHL.
Warranty: Backed by a 12-month warranty.
