MTL3045 Signal Isolator: Reliable 4-20mA Interface for Hazardous Areas
Product Description
The MTL3045 is a high-performance signal isolator designed to interface between control systems and field devices in hazardous locations. It accepts and transmits 0/20mA or 4/20mA signals to drive I/P converters, valve actuators, or other loads up to 800Ω. With excellent accuracy, high output capability (16V at 20mA), and robust construction, it is ideal for critical industrial automation applications.
Technical Data
- Brand: MTL
- Model: 3045
- Series: MTL3000
- Suffix: Full product suffix available upon request or see datasheet
- Input/Output Signal: 0-20mA or 4-20mA
- Input Resistance: ≤200Ω
- Maximum Load: 800Ω
- Accuracy at 20°C: Better than 20µA
- Temperature Drift: <1µA/°C
- Power Supply: 20-35V DC
- Typical Power Consumption: 65mA at 24V
Installation & Compatibility
Easy to install in standard DIN rail systems. Compatible with most current-to-pressure (I/P) converters, valve positioners, and actuators. Can be used with the MTL3046B to pass signals between two safe areas through a hazardous area.
Safety & Certifications
Approved for use in Zone 0, IIC, T4-T6 and Division 1, Group A hazardous locations. Complies with international safety standards. Um = 250V.
Package Includes
- One MTL3045 Signal Isolator
- Installation guide
- Replacement fuse (125mA)
Shipping & Warranty
We ship worldwide via FedEx, UPS, and DHL. This product is covered by a 12-month manufacturer warranty against defects.
