Product Overview
The Bently Nevada 330104-00-08-05-02-CN 3300 XL 8 mm Proximity Probe delivers precision in compact industrial applications. Designed with a fully threaded M10x1 body and 80 mm case length, it optimizes space efficiency without compromising durability. Its Viton® O-ring ensures leak-proof performance under pressure, while the PPS tip resists chemical corrosion. Tailored for country-specific certifications, this probe supports global compliance and integrates a ClickLoc connector for reliable signal transmission in high-vibration settings.
Technical Specifications
- Brand: Bently Nevada
- Model: 3300 XL 8 mm Proximity Probe
- 330104-00-08-05-02-CN Suffix Breakdown:
- 00: Fully threaded (0 mm unthreaded length)
- 08: 80 mm overall case length
- 05: 0.5-meter cable (1.6 feet)
- 02: Miniature ClickLoc connector (standard coaxial)
- CN: Country-specific agency approvals
- Electrical:
- DC Resistance: 7.45 ± 0.15 Ω (center to outer conductor)
- Power Range: -22 Vdc to -30 Vdc (-25 Vdc nominal with barriers)
- Output Impedance: 70 Ω
- Sensitivity: <1.0 mV/V (stable output under voltage shifts)
- Mechanical:
- Case Material: AISI 321 stainless steel (high-temperature oxidation resistance)
- Tip Material: PPS with titanium-coated abrasion shield
- Thread Design: M10x1 with vibration-resistant locking collar
- Pressure Tolerance: 40 bar differential pressure sealing
Contact Support
For certification documents or custom configurations:
sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
