Description
Product Overview
- Manufacturer
- Bently Nevada
- Part Number
- 3500/05-02-04-00-00-01
- Product Family
- 3500 System
- Rack Type
- Mini System Rack
- Origin
- Made in U.S.A
Part Number Logic
- 3500/05
- 3500 platform rack base
- 02
- 12 inch mini rack frame
- Supports 7 modules
- 04
- Rack mount format for mini rack
- 00
- No agency approvals selected
- 00
- No reserved options
- 01
- Standard factory configuration
Mechanical Size
- Width
- 304.8 mm
- Height
- 265.94 mm
- Depth
- 349.25 mm
- Weight
- About 10 kg
Rack Capacity Options
- Mini Rack
- 7 monitoring module slots
- Compact footprint
- Full Size Rack
- 14 module slots available
- Used for large systems
Mounting Styles
- Rack Mount
- Fits standard EIA rails
- Rear wiring access
- Panel Mount
- Clamps secure rack to panel
- Rear cable access
- Bulkhead Mount
- Front access wiring
- Not available for mini rack
Performance Highlights
- Rigid metal frame for long life.
- Stable airflow design.
- Supports continuous operation.
- Easy module insertion and removal.
- Clean internal grounding layout.
Typical Applications
- Machine protection systems.
- Compressor monitoring.
- Small turbine packages.
- Industrial test benches.
Warranty and Shipping
- 12 months warranty included.
- Quality checked before dispatch.
- Global shipping via FedEx UPS or DHL.
Professional FAQ
- Is the mini rack enough for future growth
- Choose full size rack if expansion is planned.
- Can this rack run nonstop
- Yes, it supports continuous industrial duty.
- Does it support dual power modules
- Yes, compatible with redundant power layouts.
- How do I select rack width
- Count required modules before selection.
- Is rear access required for wiring
- Yes, rack mount needs rear clearance.
