Description
Product Overview
The Bently Nevada 3300 XL 8 mm Proximity Probe (Product No. 330104-00-15-10-01-05) delivers precision monitoring for hazardous industrial environments. Featuring a 150 mm stainless steel case and M10 x 1 armored threading, it meets CSA, ATEX, and IECEx certifications for explosive atmospheres. Additionally, the probe integrates a 1.0-meter shielded cable with ClickLoc connector protector, ensuring stable signal transmission. Calibrated for AISI 4140 steel targets at 1.27 mm, it operates reliably between +18°C and +27°C and up to 2000 meters altitude.
Technical Specifications
| Category | Details |
|---|---|
| Brand | Bently Nevada |
| Model | 3300 XL 8 mm Proximity Probe |
| Product Number | 330104-00-15-10-01-05 |
| Suffix Breakdown | -00: 0 mm unthreaded length -15: 150 mm case length -10: 1.0 m cable -01: ClickLoc connector with protector -05: CSA/ATEX/IECEx certifications |
| Tip Material | Polyphenylene Sulfide (PPS) |
| Case Material | AISI 303/304 Stainless Steel |
| DC Resistance | 7.59 ± 0.50 Ω (1.0 m cable) |
| Certifications | CSA, ATEX, IECEx (hazardous area compliance) |
| Thread Standard | ISO 262 M10 x 1 metric fine |
| Cable Flexibility | Minimum bend radius: 25 mm (1 inch) |
| Humidity Tolerance | 0–95% RH (non-condensing) |
Contact Information
For ESD/EMC test reports or custom packaging: sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
