Description

Product Overview

The Bently Nevada 3300 XL 8 mm Armored Probe (Model 330141-08-50-01-05) is a certified industrial sensor engineered for hazardous and high-stress environments. Featuring CSA, ATEX, and IECEx approvals, this probe combines explosion-proof compliance with rugged durability. Its 5.0-meter armored cable and ClickLoc connector protector ensure reliable performance in explosive atmospheres, while the stainless steel armor and 8 mm PPS plastic tip resist mechanical stress. Ideal for oil refineries, chemical plants, and gas processing, this probe excels in extreme temperatures and corrosive conditions.

Technical Specifications

• Brand: Bently Nevada
• Model: 330141-08-50-01-05
  • Suffix Breakdown:
    • 08: 0.8-inch case length
    • 50: 5.0-meter cable (16.4 feet)
    • 01: ClickLoc connector with protector + standard cable
    • 05: CSA, ATEX, IECEx certifications
• Probe Tip: Polyphenylene sulfide (PPS)
• Armor Material: 316L stainless steel braided shielding (0.5 mm thickness)
• Temperature Range:
  • Standard: -62°F to +350°F (-52°C to +177°C)
  • Extended: Tip up to +425°F (+218°C); cable/connector up to +500°F (+260°C)

Compliance & Reliability

• Standards:
  • IECEx Scheme (IEC 60079-0/11), NEC 500 (Class I, Division 1), API 670 (machinery protection).
• Material Certification:
  • 316L stainless steel compliant with ASTM A276 for pitting/crevice corrosion resistance.
• Reliability Testing:
  • 100% Hi-Pot tested at 1,500 V AC for 60 seconds.
  • MTBF: 250,000 hours (calculated per Telcordia SR-332)

Contact Support

For certification documents or custom configurations:
sales@ubestplc.com

Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
