Product Description
Brand: Bently Nevada
Model: 330851-02-000-030-10-00-05
Product Type: 3300 XL 25 mm Proximity Probe
Country of Origin: Made in U.S.A
The Bently Nevada 3300 XL 25 mm Proximity Probe is engineered for extreme environments. It offers robust and accurate non-contact vibration and position measurement for steam turbines and large rotating machinery. It replaces standard 7200 series probes and performs reliably in hot, high-vibration conditions.
Technical Specifications
- Model Number: 330851-02-000-030-10-00-05
- Case Type: M30x2 Thread
- Unthreaded Length: 0 in
- Case Length: 30 mm
- Total Length: 1.0 metre (3.3 ft)
- Armor: No Armor
- Agency Approvals: Multiple Approvals
- Operating Temperature: -35°C to +200°C (-31°F to +392°F)
- Short-term Temp: Up to +250°C (482°F) for less than 24 hours
- Resistance: 6.2 ± 0.5 ohms (at 1 m length)
- Material: Probe Tip – PEEK; Case – AISI 304 SST
- Cable Type: 75 Ω triaxial, PFA insulated FluidLoc
- Weight: Approx. 230 g (no armor)
- Recommended Torque: 68 N·m (50 ft·lb)
Installation Guide
Install using standard threaded M30x2 mount. Tighten to a recommended torque of 68 N·m. Ensure compatibility with FluidLoc triaxial cabling. Suitable for both side and rear exit configurations.
Compatibility
Direct replacement for 7200 25 mm, 7200 35 mm, and 25 mm DE Integral transducer systems. Designed for use in Bently Nevada monitoring systems.
Certifications & Compliance
- FCC Part 15 compliance
- EMC: EN 61000-6-2, EN 61000-6-4
- RoHS: 2011/65/EU
- ABS 2009 Maritime Certified
- Hazardous Areas: Zone 0 & Zone 2 Certified (see safety drawings 141092 & 140979)
Temperature Ratings
- T1: -55°C to +232°C
- T2: -55°C to +177°C
- T3: -55°C to +120°C
- T4: -55°C to +80°C
- T5: -55°C to +40°C
Packaging & Warranty
Each unit is securely packaged with anti-static wrapping.
Includes probe and factory test report. Backed by 12-month warranty
Application Example
Ideal for steam turbine thrust position monitoring in power generation.
