Description
Complete Product Configuration
Bently Nevada 3300 XL 25mm Probe
Full Model: 330851-02-000-080-50-01-05
Full Suffix Decoding
- 330851- Base Model
- 02 – M30x2 Threaded Case
- 000 – 0in Unthreaded Length
- 080 – 80mm Total Case Length
- 50 – 5.0m (16.4ft) Cable
- 01 – Stainless Steel Armor
- 05 – ATEX/IECEx/ABS Certifications
Technical Specifications for 330851-02-000-080-50-01-05
▸ Electrical:
• Resistance: 7.5Ω ±0.8 (5m cable)
• Cable Type: 75Ω Triaxial
▸ Mechanical:
• Weight: 330g (11.6 oz)
• Max Torque: 163 N·m (120 ft·lb)
▸ Materials:
• Tip: PEEK Polymer
• Case: AISI 304 SST
• Cable Armor: 316L SST
Certifications (Suffix 05)
- Explosive Areas: ATEX/IECEx Zone 0/2
- Marine: ABS Rules 4-9-7/13
- Global: FCC/EMC/RoHS
Temperature Performance
| Condition | EPL Ga/Gc | EPL Dc |
|---|---|---|
| Standard | -55°C to +232°C | T280°C @ -55°C |
| Emergency | 250°C (24h max) | T225°C @ -55°C |
Industrial Applications
Oil RefineriesMonitors catalytic cracker turbines at 230°C+
Pharma AutoclavesWithstands 150°C steam sterilization cycles
Paper MillsSurvives high-humidity dryer sections
Package Contents
- 1x Probe (80mm armored case)
- 5m SST-Armored FluidLoc® Cable
- ATEX/IECEx/ABS Compliance Documents
- Torque Guide (68-163 N·m)
Contact Support
Email sales@ubestplc.com for hazardous area schematics.
