Description
Product Summary
Bently Nevada 3300 XL 25mm Probe (Model: 330851-02-000-030-50-01-00) is a high-performance sensor for tough conditions. Made in the USA, it has a 30mm case, 5.0m cable, and SST armor. Perfect for long-distance monitoring in extreme heat.
Technical Specifications
Brand: Bently Nevada
Model Code: 330851-02-000-030-50-01-00
Code Breakdown:
- 02: M30x2 Threaded Case
- 000: 0″ Unthreaded Section
- 030: 30mm Case Length
- 50: 5.0m Cable
- 01: SST Armor Included
- 00: No Agency Approvals
Key Data:
- Resistance: 7.5Ω ±0.8 (5.0m cable)
- Temperature: -35°C to +200°C (Up to 250°C for 24h)
- Weight: 330g (with armor)
- Cable: 75Ω Triaxial, PFA Insulation
Installation Guide
- Max Torque: 163 N·m (120 ft·lb)
- Safe Torque: 68 N·m (50 ft·lb)
- Materials:
- Case: Stainless Steel (AISI 304)
- Tip: PEEK Plastic (Heat-Resistant)
Certifications
- EMC: EN 61000-6-2, EN 61000-6-4
- RoHS: Compliant
- Maritime: ABS 2009 Certified
- ATEX: AEx/Ex ia IIC (Zone 0) & AEx/Ex ec (Zone 2)
Real Applications
- Wind Turbines: Monitor gearbox vibrations with 5m cable reach.
- Chemical Plants: Resist corrosion in high-heat reactor zones.
- Marine Engines: Survive salty environments with SST armor.
Package Details
- Included: Probe, 5.0m Cable, Manual
- Warranty: 1 Year (Defect-free guarantee)
Contact: Email sales@ubestplc.com for quotes or support.
