Description
Core Features for 330851-02-000-066-90-00-CN
- ???? 66mm Medium Case (Code 066)
- ???? 9m Flexible Cable (Code 90)
- ???? China-Specific Certifications (Code CN)
- ???? 8.8Ω ±1.1 at 9m Length
Model Code Breakdown for 330851-02-000-066-90-00-CN
| Code | Description |
|---|---|
| 02 | M30x2 Thread |
| 000 | 0in Unthreaded |
| 066 | 66mm Case |
| 90 | 9.0m Cable |
| 00 | No Armor |
| CN | GB/T China Standards |
Technical Specifications
| Parameter | Value |
|---|---|
| Range | 25mm |
| Resistance (9m) | 8.8Ω ±1.1 |
| Operating Temp | -35°C to +200°C |
| Peak Temp (24h) | 250°C |
| Weight | 230g (8.1oz) |
| Cable Type | 75Ω Triaxial PFA |
Installation Guide
- ???? Max Torque: 163 N·m (120 ft·lb)
- ???? Recommended Torque: 68 N·m (50 ft·lb)
- ???? Compatibility: Replaces 7200 25mm DE systems
Certifications
- ✅ China GB/T 3836-2010 (Explosive Atmospheres)
- ✅ FCC Part 15 & EN 61000 EMC
- ✅ RoHS 2011/65/EU Compliant
- ✅ ABS Marine Certified
Industry Application
Monitors pharmaceutical tablet presses detecting mechanical wear in 24/7 production lines with 180°C sterilization cycles.
Package Contents
- ???? 1x Probe (66mm Case)
- ???? 9m PFA Cable
- ???? 1-Year Pharma-Grade Warranty
Contact Support
???? sales@ubestplc.com
