Description
Core Features for 330851-02-000-050-90-00-05
- ⚡ 50mm Compact Design (Code 050)
- ⚡ 9m Long-Reach Cable (Code 90)
- ⚡ Multi-Certified (Code 05)
- ⚡ 8.8Ω ±1.1 Accuracy at 9m
Full Model Code Breakdown for 330851-02-000-050-90-00-05
| Position | Code | Specification |
|---|---|---|
| 1-2 | 02 | M30x2 Threaded |
| 3-5 | 000 | 0in Unthreaded |
| 6-8 | 050 | 50mm Case |
| 9-10 | 90 | 9.0m PFA Cable |
| 11-12 | 00 | No Armor |
| 13-14 | 05 | ATEX + ABS + IECEx |
Key Specifications
| Parameter | Value |
|---|---|
| Measurement Range | 25mm |
| Resistance (9m) | 8.8Ω ±1.1 |
| Temp Range | -35°C to +200°C (+250°C for ≤24hrs) |
| Weight | 230g (8.1oz) |
| Max Torque | 163 N·m (120 ft·lb) |
Installation Guide
- ???? Use 68 N·m torque (50 ft·lb)
- ???? Compatible with 7200 DE systems
- ???? Check PEEK tip alignment
Certifications
- ✅ ATEX Zone 0: Ex ia IIC T4
- ✅ IECEx Ex nA IIC T4
- ✅ ABS Marine Rule 4-9-7/13
- ✅ FCC/EMC/RoHS Compliant
Industry Application
Monitors pharmaceutical autoclaves detecting steam valve vibrations in sterile production environments (+180°C).
Package Contents
- ???? 1x Probe (50mm case)
- ???? 9m FluidLoc® Triaxial Cable
- ???? 1-Year Critical Use Warranty
