Product Description
The Bently Nevada 3300 XL 25 mm Proximity Probe (Model: 330851-02-000-080-50-01-CN) is built for extreme industrial conditions, featuring a stainless steel armor and 5.0-meter cable. It replaces older 25 mm/35 mm probes and works in high-heat environments up to 250°C (482°F).
Technical Data
| Brand | Bently Nevada |
|---|---|
| Model | 3300 XL 25 mm Proximity Probe |
| Full Suffix | 330851-02-000-080-50-01-CN |
| Case Type | M30x2 Thread (Option 02) |
| Armor | SST Armor (Option 01) |
| Cable Length | 5.0 meters (16.4 feet) |
| Probe Resistance | 7.5 Ω ±0.8 |
| Operating Temp | -35°C to +200°C |
| Short-Term Temp | 250°C (24h max) |
Installation Guide
- Max Torque: 163 N•m (120 ft•lb)
- Recommended Torque: 68 N•m (50 ft•lb)
- Weight (with armor): 330 g (11.6 oz)
Compatibility
Works with 7200 series probes and 25 mm DE Integral systems. Suitable for side/rear exit setups.
Certifications
- FCC Part 15
- EN 61000-6-2/4
- RoHS Directive
- Country-Specific Approval (CN)
- ABS Maritime
Package & Warranty
- Probe with 5m armored cable
- Installation guide
- 1-year limited warranty
Application Example
Used in oil refinery compressors to monitor shaft vibration under high dust and heat (up to 200°C).
