Description
Product Description
The Bently Nevada 3300 XL 25 mm Proximity Probe (Model: 330851-02-000-080-90-00-00) is designed for harsh industrial environments, including steam turbines. It replaces legacy 25 mm and 35 mm probes, offering high-temperature resistance up to 250°C (482°F) and durable construction with a stainless steel case and PEEK tip.
Technical Data
| Brand | Bently Nevada |
|---|---|
| Model | 3300 XL 25 mm Proximity Probe |
| Full Suffix | 330851-02-000-080-90-00-00 |
| Range | 25 mm |
| Accuracy | ±1.1 ohms (Probe Resistance) |
| Output Signal | 75 Ω Triaxial Cable |
| Operating Temp | -35°C to +200°C |
| Cable Length | 9.0 meters (29.5 feet) |
Installation Guide
| Torque (Max) | 163 N•m (120 ft•lb) |
|---|---|
| Torque (Recommended) | 68 N•m (50 ft•lb) |
| Weight | 230 g (8.1 oz) without armor |
Compatibility
Replaces 7200 25 mm, 7200 35 mm, and 25 mm DE Integral systems. Works with side/rear exit probes.
Certifications
- FCC Part 15
- EN 61000-6-2/4
- RoHS Directive
- ABS Maritime
- ATEX/IECEx Certified
Package & Warranty
- Probe with PFA cable (1m, 5m, or 9m)
- 1-year limited warranty
Application Example
Used in steam turbine DE applications to monitor vibration under extreme temperatures up to 250°C.
