Bently Nevada – Proximity Probe M30x2 Thread 330851-02-000-080-90-01-00

Description

Product Overview

Bently Nevada 3300 XL 25 mm Proximity Probe (Model: 330851-02-000-080-90-01-00) is built for extreme industrial conditions. Made in the USA, it replaces older 25 mm/35 mm probes and works in steam turbines, compressors, and high-heat zones.

Technical Specifications for 330851-02-000-080-90-01-00

• Brand: Bently Nevada
• Model: 3300 XL 25 mm Proximity Probe
• Full Suffix Code:
  • 330851: Base model
  • 02: M30x2 threaded case
  • 000: 0-inch unthreaded length
  • 080: 80mm case length
  • 90: 9.0-meter cable (29.5 ft)
  • 01: No armor
  • 00: No agency approvals
• Measurement Range: 25 mm
• Probe Resistance: 8.8 Ω ±1.1 (9.0 m cable)
• Temperature Range:
  • -35°C to +200°C (continuous)
  • 250°C max (24 hours max)
• Cable: 75 Ω triaxial, 9.0 m PFA-insulated
• Weight: 330 g (with armor, 1m cable)

Installation & Use

• Torque: Use 68 N•m (50 ft•lb) for threaded cases.

Certifications

• FCC Part 15 compliant
• EN 61000-6-2/6-4 (EMC)
• RoHS 2011/65/EU
• ABS Maritime certified

Applications

• Hydroelectric Plants
• Chemical Processing
• Wind Turbines

Package Contents

• Probe with 9.0 m cable

Warranty: 12 months from delivery.

Contact: For pricing, email sales@ubestplc.com.

Download official datasheet here: 3300-XL-25MM-Datasheet
