Description
Industrial Monitoring Solution
Bently Nevada 3300 XL Probe
Model: 330851-02-000-080-90-00-CN
80mm Case • 9m Cable • China-Certified
Full Product Code Breakdown for 330851-02-000-080-90-00-CN
| 330851- | Base Model |
| 02 | M30x2 Threaded Connection |
| 000 | 0in Unthreaded Length |
| 080 | 80mm Case Length |
| 90 | 9.0m Cable (29.5ft) |
| 00 | No Armor |
| CN | China-Specific Certifications |
Technical Specifications
▷ Electrical
• Resistance: 8.8Ω ±1.1 (9m cable)
• Frequency Range: 10Hz-12kHz
• Cable Type: 75Ω Triaxial PFA
▷ Mechanical
• Weight: 230g (8.1oz)
• Torque Range: 68-163 N·m
• IP67 Environmental Rating
China Certifications (CN Code)
- GB/T 3836-2017 Ex ia IIC T4 (Explosive Atmospheres)
- CCC Mark: CNCA-C22-01:2020
- HJ 517-2021 (Industrial EMC Compliance)
Industrial Applications
High-Speed RailMonitors traction motor bearings in 200km/h+ environments
Hydropower PlantsTracks turbine shaft vibrations in humid dam facilities
Environmental Performance
| Parameter | Standard | Peak (24h) |
|---|---|---|
| Temperature | -55°C to +232°C | +280°C |
| Vibration | 20g @ 10Hz-5kHz (IEC 60068-2-6) | |
Package Contents
- 1x Probe (80mm case)
- 9.0m FluidLoc® Cable
- GB/T Test Reports (Chinese/English)
- 1-Year China Warranty
